ไขควงทอร์คไฟฟ้าแบบออโตเมติก BSD-8000L Torque Screwdriver

DESCRIPTIONS:

• New technology, fully automation, as fastened screw reach preset torque, clutch will stops immediately.
• Friendly holder, free from fatigue under long-time using and improve production efficiency.
• Low-voltage with power controllers, no influence by fluctuated voltage can keep long-time operation.
• Precise torque, torque adjusted from small to large, stepless and stable.
• Rotation speed can select by switch Hi & LO or adjust freely by VR.
• Complete series to provide full torque range (0.2~48kgf.cm) for all general applications such as cel phone, digital camera, PDA, DVD, Notebook, PC, office machine and other peripherals, etc..

SPECIFICATIONS:

• Model: BSD-8000L
• Input voltage: 24VDC or 32VDC
• Rated input: 50W
• Torque range:
  • 5-18Kgf.cm
  • 4.4-15.84Lbf.in
  • 0.5-1.76N.m
• Unload Speed HI/LO ±10%: 1,000/700RPM
• Metal assembly screw:
  • Machine screw: 2.0-3.5mm
  • Tapping screw: 2.3-3.0mm
• Torque Accuracy: ±3%
• Torque Adjustment: Stepless
• Weight: 600g
• Length: 260mm
• ESD (Anti-Static): Yes
• RoHs: Yes
• Model of Torque Fixing Ring: KC-2
• Suspension Rack: KH-3
• Bit Type: HEX 5mm, HEX 6.35mm, Ø4mm, Ø5mm
• Power controller: BSP-32HL/32VE-60W
