ไขควงไฟฟ้าปรับทอร์ค BSD-6600LP Push Start-Automatic Stop

DESCRIPTIONS:

• New technology, fully automation, as fastened screw reach preset torque, clutch will stops immediately.
• Friendly holder, free from fatigue under long-time using and improve production efficiency.
• Low-voltage with power controllers, no influence by fluctuated voltage can keep long-time operation.
• Precise torque, torque adjusted from small to large, stepless and stable.
• Rotation speed can select by switch Hi & LO or adjust freely by VR.

SPECIFICATIONS:

• Model: BSD-6600LP
• Input voltage: 32VDC
• Rated input: 48W
• Torque range:
  • 3-16Kgf.cm
  • 2.57-13.89Lbf.in
  • 0.29-1.57N.m
• Unload Speed HI/LO ±10%: 1,000/700RPM
• Metal assembly screw:
  • Machine screw: 2.3-3.5mm
  • Tapping screw: 2.3-3.0mm
• Torque Accuracy: ±3%
• Torque Adjustment: Stepless
• Weight: 480g
• Length: 230mm
• Model of Torque Fixing Ring: KC-3
• Bit Type: HEX 5mm, HEX 6.35mm, Ø4mm, Ø5mm
• Power controller: BSP-32HL-40W, BSP-32VR-40W
