เครื่องวัดความเรียบผิว Surface Roughness Tester TR-200

Descriptions:

The hand-held roughness tester is a new product developed by IPRE. This tester applies to production site and can be used to measure surface roughness of various machinery-processed parts, calculate parameters according to selected measuring conditions and clearly display all measurement parameters and profile graphs on LCD.

Product advantages:

• Supports 17 parameters: Ra,Rq,Rz,Rv,Rp,Rm,Rt,RS,RSm,R3z,R5z, R3y,Rz(JIS),Rsk,Rku,Rmax,Rpc
• Measuring Range: Ra,Rq:0.005-16μm; Rz,Ry,Rt,Rp,Rv,Rmax,R3z,Rz(JIS):0.02-160μm; RS, RSm:1mm; Rmr:0-100%(%Rt), Rsk, Rku,Rpc :0-100%
• Display used OLED, has the characteristics of self-luminous, full visual angle, wide temperature and so on.
• Use special sensor RS210, interchangeable in IPRE products, can assure high linear measurement due to built-in calibration curve.
• Remote upgrade the embedded software.
• Sensor developed and produced independent.
• Curved surface sensor used circular guide head suite for a variety of conditions.
• Use ARM processor, has powerful computing power and control ability. Parameters are the most completed in similar products.
• Support wireless printing and data transmission and Bluetooth printing and transmission.

Specifications:

• Measurement Parameters: Ra,Rz,Ry,Rq,Rt,Rp,Rv,Rmax,R3z,RSk,RS,RSm,Rmr
• Measurement range: Ra:0.025-12.5μm
• Display range: Ra,Rq:0.005-16μm;Rz,Ry,Rt,Rp,Rv,Rmax,R3z:0.02-160μm;RS,RSm:1mm;Rmr:0-100%(%Rt);Rsk:0-100%
• Measuring range: ±20μm,±40μm,±80μm
• Highest resolution: 0.001μm
• Filter: RC,PC-RC,GAUSS,D-P
• Sampling length l: 0.25mm,0.8mm,2.5mm
• Evaluation length L: (1-5)l(optional) l is sampling length
• Maximum drive stroke: 17.5mm/0.7inch
• Minimum drive stroke length: 1.3mm/0.052inch
• Indication error: ≤±10%
• Indicated value variability: ≤6%
• Display mode: 128×64 OLED Lattice liquid crystal (self luminescent)
• Power: Built-in rechargeable lithium battery
• Overall dimension: 140mm×52mm×48mm
• Weight: 440g
