Digitorqon HDT-series H3DT135
฿0.00
Digitorqon HDT-series H3DT135
รายละเอียดสินค้า Digitorqon HDT-series H3DT135
Digitorqon HDT-series H3DT135
DIGITORQON HDH-series is a digital torque measurement device mounted between the manual handle, such as a ratchet handle, a spinner handle, ete., and the socket.
2 measurement modes (peak & tracking) available in both CW and CCW directions.
Alert by beeping sound when reaching the target torue.
Set the beepsound function arbitrarily between 50% and 95% of the target torque.
SPECIFICATIONS:
- Model : H3DT135
- Capacity Torque Range (N.m) Min. ~ Max. : 10 ~ 135
- Unit : N.m
- Square Drive Male/Female (mm) : 9.5
- Dimensions (mm) W : 45
- Dimensions (mm) T : 45
- Dimensions (mm) D : 24
- Dimensions (mm) L : 75
- Weigth (kg) : 0.194
- Case Size (mm) : 130x107x53
*Exclude battery:
- Repeated Accuracy:+/-3%
- Battery:AAA Alkaline BatteryX2
- Torque Readout (Unit:N.m)
- H3DT135:0.01 increment (from 10.00 to 99.99N.m), 0.1 increment (from 100.0 to 135.0N.m)
- Operating Temperature: 5°C~42°C
- Storage Temperature: -20°C~50°C
- Repeated Accuracy: ±3%
Accessory:
- Calibration Certificate W/H Traceablilty : 1
- Instruction Manual : 1
- Plastic Case : 1
- AAA Alkaline Battery : 2
