เครื่อหยอดกาวอัตโนมัติ Dispensing Controller B-800

Technical Data:

• Power consumption: 8W
• Air source: max 0.99 Mpa    Pressure setting: 0.05-0.99 Mpa
• Time setting: DIP switch 0.01-1s; 0.1-10s; 0.2-20s; 0.3-30s
• Control mode: Manual / Quantitative (fixed volume dispensing)
• Repetitive accuracy: ± 0.05%    Dispensing frequency: 600/min
• Min. dispensing volume: 0.01 ml
• Dimension: 235mm x 225mm x 63mm      Weight: 2.2 Kg

Applications:

• Materials for dispensing:
  • Solder tin, Tin paste, UV adhesive, Lubricant, Epoxy resin,
• fast cure adhesive, silicone resin, etc.
• Usage: adhering, fixing, dot coating, line coating, etc.
